Welded Wire Mesh Machine

High speed Welded Wire Mesh Machine The high-speed welded wire mesh machine is composed of a main machine and an auxiliary machine. The auxiliary machine includes a mountain line (spool), a supplementary net table, a net filling machine, a shafting machine, a joint machine and the like. The production speed is fast, the operation is simple, the manpower is saved, and the control system adopts the international famous brand PLC. The finished product is automatically wound up, which is convenient for transportation.
没有此类产品
Product description

Welded Wire Mesh Machine

Products Description

1. Both longitude wire and cross wire can be feed from wire coils automatically.

2. The raw material is applicable for low carbon steel wire or stainless steel wire.

3. It has advantage such as design reasonable, low noise, more stable, easy operation and electromagnetism adjustable speed for welding.

4. The mesh size is precise and the machine can be set the width and length according to customer' s requirement.

5. All the parts of the machine are processed by our own factory; no parts were sent to outside to process, so the quality can be ensured.



6. We can provide 12 months guarantee for all the equipment, and if customer needs, we will arrange our technician to help install the machines in your country, and also could supply all the spare parts with cost price.

Parameter



 Model item

 LE-DHWJ-1

 LE-DHWJ-2

 LE-DHWJ-3

 LE-DHWJ-4

Netting width/mm

914.4; 1000mm

 1219; 1524mm

 (4 feet; 5 feet)

 1219; 1524mm

 (4feet; 5 feet)

 1219.2; 1524mm;

 1828.8; 2133.6mm

 (4feet; 5feet; 6feet;7feet)

 Aperture/pitch

 6.35- 12.7mm

 (1/4"-1/2")

 19.05mm(3/4")

 12.7-101.6mm

 (1/2"-4")

 25.4-101.6mm

 (1"-4")

 Wire diameter

 0.4-0.65mm

 0.6-1.4mm

 0.6-1.8mm

 1.2-2.5mm

 Voltage

 380V 50HZ

 380V 50HZ

 380V 50HZ

 380V 50HZ

 Motor power

 2.2kw

 2.2kw

 2.2kw

 4.0kw

 Welding speed

max 75rows/min

 max 120rows/min

 max 120rows/min

 max 85rows/min

 Overall  dimension

 2.3*1.3*1.4m

 3.0*1.75*1.65m

 2.0*1.5*1.6m;  3.0*1.75*1.65m

 2.0*1.5*1.6m;  3.0*1.75*1.65m

 Weight

 1.5T

 2.5T

 2.0T; 2.5T

 2.0;2.5;3.0;3.5T

 Welded transformer  voltage

 50KVA*3

 65KVA*5

 65KVA*4; 65KVA*5

 65KVA*4;  65KVA*5
